Efficient and reliable Hitachi EX60 second-hand excavator is a good choice

Short Description:

The Hitachi EX60 is a 6-ton excavator from Japan. It provides versatility and performance for various digging, hauling, and excavation tasks. EX60 is equipped with an Isuzu 4BG1T engine, which can output a strong power of 54.3 horsepower. Bucket capacity ranges from 0.2 to 0.4 cubic meters, with a maximum digging depth of 4.14 meters and a maximum digging range of 6.69 meters. This excavator offers reliability and durability for many different applications. It is the first choice for construction, infrastructure, mining, and other industries.


Product Detail

Product Tags

Hitachi EX60 Used Hitachi EX60 with good performance Original Japanese Import Excavator for sale

Product Description

Specification
Weight: 6100kg
Transport length: 17.6 m
Transport width: 3.5 m
Transport height: 3.42 m
Bucket capacity: 0.4 m³
Track width: 600 mm
Engine manuf: Hitachi
Engine type: SAA6D125E-5
Engine power: 257 kW
Manufacturer: Hitachi
Model: 60

Boom/Stick Excavator Option 1

Max Cutting Height 23.5 ft (7 m)
Max Digging Depth 13.7 ft (4 m)
Max Loading Height 16.7 ft (5 m)
Max Reach Along Ground 20.3 ft (6 m)
Max Vertical Wall Digging Depth 11.6 ft (3 m)
Shipping Height of Unit 8.5 ft (2 m)
Shipping Length of Unit 20 ft (6 m)

Boom/Stick Excavator Option 2

Max Cutting Height 24.8 ft (7 m)
Max Digging Depth 15.3 ft (5 m)
Max Loading Height 18 ft (5 m)
Max Reach Along Ground 21.9 ft (6 m)
Max Vertical Wall Digging Depth 13.4 ft (4 m)
Shipping Height of Unit 9.5 ft (3 m)
Shipping Length of Unit 20.1 ft (6 m)

Bucket

Maximum Bucket Capacity 0.5 cu yds (0 m)
Minimum Bucket Capacity 0.2 cu yds (0 m)
Reference Bucket Capacity 0.4 cu yds (0 m)

Dimensions

Ground Clearance 1.2 ft (0 m)
Height - Top of Cab 8.5 ft (2 m)
Removal Counterweight Clearance 2.5 ft (1 m)
Tail Swing Radius 5.8 ft (2 m)
Width to Outside of Tracks 7.3 ft (2 m)

Engine

Aspiration Natural
Displacement 180.3 cu in (0 m)
Engine Make 2311
Engine Model A-BD30
Max Torque 133.5 lbs/ft
Net Power 54 hp (40 kw)
Power Measured @ 2200 rpm
Torque Measured @ 1500 rpm

Operating Specifications

Alternator Supplied Amperage 25 A
Cooling System Fluid Capacity 2.7 gal (8 l)
Engine Oil Capacity 3.4 gal (11 l)
Fuel Capacity 9.5 gal (34 l)
Hydraulic Pump Flow Capacity 41.9 gal/min (155 l/min)
Hydraulic System Fluid Capacity 23.8 gal (87 l)
Hydraulic System Relief Valve Pressure 4550 psi
Operating Voltage 12 V
Operating Weight 13889.2 lbs (6,300 kg)
Swing Drive Fluid Capacity 0.5 gal (0 l)

The Hitachi EX60 is a robust and reliable used excavator suitable for various applications. It offers superior performance and is economical for construction, infrastructure, and mining industries. Whether you need to dig, haul, or excavate, the EX60 will give you the performance to get the job done efficiently.

Packing and Shipping

1. Container: The cheapest and fast one put the machine into container but need to be disassembled.

2. Flat rack: Often used to ship 20tons or up excavators, max load-bearing is 35 tons, no need to be disassembled.

3. Bulk  ship: Price will be cheaper than flat rack.

4. RORO ship :The machine is driven directly into the ship and does not need to be disassembled.

packing and shipping
Excavator shipment
we can also provide

KASTO Yard

shanghai kasto factory
