Used CAT336D 36ton Caterpillar Crawler Excavator
Used CAT336D 36ton Caterpillar Crawler Excavator CAT336D for sale
Product Specification
The CAT336D excavator is a powerful and versatile machine designed for heavy-duty construction and excavation work. It is part of the Caterpillar family of excavators and is renowned for its exceptional performance and durability.
The CAT336D is equipped with a robust engine that delivers impressive power, allowing it to efficiently handle even the most challenging tasks. It features a turbocharged and air-to-air aftercooled CAT C9.3 ACERT engine, which provides high torque and reliable performance.
With an operating weight of approximately 36,000 kilograms, the CAT336D is a substantial machine that can handle large-scale excavation projects. It has a maximum digging depth of 7.2 meters and a maximum reach at ground level of 10.96 meters, giving it excellent reach and maneuverability on the job site.
The 336 D L is categorised in the biggest machine segment in the crawler excavators category. The model's dimensions are 11.21m x 3.29m x 3.54m. The bucket capacity of 336 D L is 1,6m³, which is above average for this type of machine.
|
Specification |
Operating Weight (kg) |
33750 |
|
Bucket capacity (m³) |
1.4 |
|
|
Tonnage (tons) |
36 |
|
|
Walking speed (km/h) |
3.5 |
|
|
Dimensions |
Total Shipping Length (mm) |
11150 |
|
Total Shipping Width (mm) |
3190 |
|
|
Total Transport Height (mm) |
3340 |
|
|
Working Range |
Maximum Digging Radius (mm) |
10920 |
|
Maximum Digging Depth (mm) |
7390 |
|
|
Maximum Digging Height (mm) |
10240 |
The Caterpillar 336D crawler excavator is a powerful, versatile machine designed for heavy-duty construction and excavation tasks. Known for its exceptional performance, durability, and reliability, it is ideal for all excavation projects. No matter what challenge you face, the 336D delivers the power and performance to keep your engineering projects running efficiently and smoothly.
Product Overview
Video
Packing and Shipping
1. Container: The cheapest and fast one put the machine into container but need to be disassembled.
2. Flat rack: Often used to ship 20tons or up excavators, max load-bearing is 35 tons, no need to be disassembled.
3. Bulk ship: Price will be cheaper than flat rack.
4. RORO ship :The machine is driven directly into the ship and does not need to be disassembled.
